2Phase Stainless Steel Decanter Centrifuge for Plant Extraction with PLC Control

The LW series 2phase sedimentation decanter centrifuge is a horizontal, continuously working and continuously spiral discharging sedimentation centrifuge. It can be used for the sewage sludge dewatering and thickening.

• Product: 2phase decanter centrifuge
• Application: Plant extraction
• Capacity: 1-100 M³/H
• Material: Stainless steel
• Control and operation: PLC control, automatic, screen touch operation
• Discharging: Continuous and automatic
• Motor: Double motor driving
• Motor power: 4-110KW

The bowl and screw make high-speed rotation with a certain differential speed between them. The materials will enter the bowl from the feed tube. Under the action of centrifugal force field:

• The liquid of the high specific weight will accumulate on the inner walls of the bowl, and be discharged through the centripetal pump or overflow plate
• The liquids of low specific weight will form an inner liquid ring, stick to the surfaces of heavy liquids, and be discharged from the overflow channel
• Under the action of the spiral material pusher, the solids in the materials will be continuously pushed to the taper end of the bowl and discharged from the residue outlet after going through the drying area

• All parts directly touching material are made of stainless steel or duplex stainless steel
• Continuous and automatic operation minimizes labor costs
• Two motor drive with adjustable bowl and screw speed via VFD
• Special bowl and spiral design ensures high dryness cake by pressing against the dewatered cake at the conical end
• Double motor double frequency conversion with multi-stage planetary gear drive
• Wide range of wear protection options including welded hard facing, spray coating, ceramic port, and more
• Safety protections include rotation rate detection, vibration protection, motor overload protection, and more

Essential Centrifuge Safety Guidelines:

• Ensure a level and firm work surface
• Inspect and balance the tubes properly
• Keep the lid closed during operation
• Monitor for wobbling or shaking
• Use appropriate protective equipment
• Avoid moving the centrifuge during operation

Huading Separator has been at the forefront in the field of centrifugal separation technology for more than 60 years, established in 1954, and is the leader in mechanical separating technology in China. Our machines are used in a wide range of industries including:

• Beverage and dairy industries
• Oil recovery and processing
• Chemicals, pharmaceuticals, and biotechnology
• Starch technology
• Marine engineering and energy
• Oil fields and water treatment
